Switching and Measurement cell

Switching and Measurement cell Switching and Measurement cell immersed in coolant biodegradable “FR3” 24 kV class, 80 amps, has the following characteristics: – One (1) isolated three-phase input 24 kV class, type bushing inserts (MUFAs include elbow) with enclosure protection and cable ties. – One (1) general disconnect under load class 24 kV FR3 immersed…

Details

Expomin 2012

International Representatives GERMANY & EUROPE Messe Dusseldorf – Gmbh Mr. Cem Bagci Tel: +49 / (0) 211 / 45607705 Fax: +49 / (0) 211 / 45607740 bagcic@messe-duesseldorf.de ASIA Asia Reps Ms. Shen Yughan Tel: (56-2) 381 17 77 shen@asiareps.cl AUSTRALIA Australian Embassy Ian Frederick Senior Business Development Manager Tel: (56-2) 733 47 77 Fax: (56-2)…

Details

7500/10000 KVA Power Transformer in 13.8 KV

Three phases power transformer, with separate side boxes sealed, for primary and secondary bushings. Self-cooled transformer, submerged in mineral oil, weatherproof and waterproof type. The transformer was designed, built and tested to ANSI C and ANSI C 57.12.90 57.12.00.

Oil Current Transformer 1200/5-5 Volts 25 KV class

Current transformer manufactured according to ANSI C57.13 norm, isolated it in mineral dielectric oil, 50 Hz frequency, sealing pond, open type pond, 25 kV insulation class, 1000 meter above sea level. Accuracy class N1 and N2: 5P20, 50 VA burden, ratio 1200/5 – 5 Volts.

300 KVA Dry type transformer in 380/690 Volts

600 KVA dry type transformer 380/690 Volts features:

  • Power: 300 KVA
  • Voltages: 380/690 Volts
  • Frequency: 50 Hz
  • Transformer class “H”
  • Factor K = 1
  • Temperature rise: 115 ° C
  • Connection group: dD0
  • Operating Altitude: 1,000 m.s.n.m
  • Insulation level: 600 Volts
  • Metal enclosure: NEMA 1 (RAL 7032)

2000 KVA 15 KV Unit Substation

UNIT SUBSTATION 2000 KVA in 15 KV. General features of the assembly unit.

The substation unit cell consists of a medium voltage cell (MVC), a low voltage cell (LVC) and a transformer unit. The entire set is for outdoor use and all mounted it on a skid type.

1500 KVA 25 KV Unit Substation

General features of the entire unit substation.

The unit substation consists of a cell medium voltage (MV), a cell low voltage (LV) and a transformer, all the whole assembly mounted on a skid type.
